Steel bar truss production line

Self-support steel bar truss deck production line is a steel bar machine that welds longitudinal bars and web bars together at a certain distance. Consists of truss welding line bottom panel forming machine and board spot welding machine. Combining mechanism, electricity, hydraulic and pneumatics with microcomputer control, it performs whole set production process of steel molding board’s truss, galvanized steel forming and assembling & welding. Profiles and sizes are customized as per customers' requirements.

DETAIL PICTURE

Self-support-Steel-Bar-Truss-Deck-Production-Line1
Self-support-Steel-Bar-Truss-Deck-Production-Line2
Self-support-Steel-Bar-Truss-Deck-Production-Line3
Self-support-Steel-Bar-Truss-Deck-Production-Line4

PROCESS FLOW

PARAMETER

Diameter of upper rebar

8-12mm

Diameter of lower rebar

6-12mm

Diameter of web rebar

4-8mm

Height of steel truss

70-270mm

Diameter of horizontal rebar

10mm(for h≤100mm), 12mm(for height >100mm)

Diameter of vertical rebar

12mm(for h≤100mm), 14mm(for height >100mm)

Thickness of base sheet

0.4-0.6mm

Width of base sheet

576mm, 600mm

Thickness of concrete

15mm, 20mm, 25mm, 30mm, 45mm

Length of steel bar truss

1.0—12m
