Suitable for thickness 0.8-3.0mm, width 100-1250mm
For material steel, aluminum and stainless steel
Speed 0-30m/min, or 4-6pcs/min by 2m plate
Length tolerance ±1.5mm
Leveling precision, perfect surface
Automatic PLC control system
Contact by office@willingint.com or 0086 13588279758
|
Material |
Type |
Colored or galvanized steel sheet |
|
Thickness（mm） |
0.8-3.0 |
|
|
Yield stress（Mpa） |
230-300 |
|
|
Max. Forming speed（m/min） |
0-15m/min or 0-30m/min |
|
|
Roller material |
Cr12 |
|
|
Roller driven type |
Chain transmission |
|
|
Controller |
PLC |
|
|
Operation |
Touch screen and button |
|
|
Hydraulic system pressure（Mpa） |
12 |
|
|
Main motor power（KW） |
3 |
|
|
Total weight（Kg） |
About 5000 |
|
